RS-485

Port pinning

RS-485 pinning

Digi Key order # 2150-22008231-01-ND

PinFunctionPinFunction
1GND5GND
2VIN6VCC
3Module A7RS-485 A
4Module B8RS-485 B
Pinning RS-485
